| Amperage Draw @ 230v 3ph | 18A |
| Collet Capacity | 1/8" to 7/8" |
| Max. Distance Spindle To Column | 21 2/5" |
| Max. Distance Spindle To Table | 18 3/4" |
| Motor Hp | 3 hp |
| Motor Phase | 3 |
| Motor Voltage | 230V |
| No. Of Axis | 3 |
| Overall Dimensions | 68" x 63" x 84" |
| Quill Dia. | 3 3/8" |
| Quill Down Feed Rates | 0.0015, 0.003, 0.006 |
| Range Of Spindle Speeds | 60-5000 RPM |
| Spindle Taper | R-8 |
| Spindle Travel | 5" |
| Style | Variable Speed |
| T-slot Centers | 2 1/2" |
| Table Cross Travel | 12" |
| Table Length | 9" |
| Table Longitudinal Travel | 36" |
| Table Width | 49" |
| Travel Of Knee | 16" |
| Travel Of Ram | 14" |
| Work Table Weight Capacity | 550 lbs. |
| Ship weight (kg) | 1102.5 |
| Ship height (cm) | 213.36 |
| Ship length (cm) | 172.72 |
| Ship width (cm) | 160.02 |
| Country of Origin | TW |
