| Inverter Type | B, Delta |
| Collet Capacity | 1/8" to 7/8" |
| Column Width | 18" |
| Max. Distance Spindle To Column | 18 1/8" |
| Max. Distance Spindle To Table | 20 3/4" |
| Motor Hp | 3 hp |
| Motor Phase | 3 |
| Motor Voltage | 230V |
| No. Of Axis | 3 |
| Overall Dimensions | 67" x 64" x 86" |
| Powerfeed | X And Y Axis |
| Quill Dia. | 3 3/8" |
| Quill Down Feed Rates | 0.0015, 0.003, 0.006 |
| Range Of Spindle Speeds | 60-4500 RPM |
| Saddle Width | 11 1/2" |
| Spindle Taper | R-8 |
| Spindle Travel | 5" |
| Style | EVS |
| T-slot Centers | 2 1/2" |
| Table Cross Travel | 12 5/8" |
| Table Length | 9" |
| Table Longitudinal Travel | 36" |
| Table Longitudinal Travel With Powerfeed | 30 3/4" |
| Table Width | 49" |
| Travel Of Knee | 15 3/4" |
| Travel Of Ram | 15 1/4" |
| Work Table Weight Capacity | 720 lbs. |
| Ship weight (kg) | 1089 |
| Ship height (cm) | 218.44 |
| Ship length (cm) | 170.18 |
| Ship width (cm) | 162.56 |
| Country of Origin | TW |
