| Cross Slide Travel | 7 |
| Number Of Inch Threads | 34 |
| Number Of Metric Threads | 34 |
| Compound Slide Travel | 3 1/2" |
| Cross Slide Travel | 7" |
| Length Of Gap | 9 1/2" |
| Max. Tool Size | 3/4" x 3/4" |
| Motor Hp | 3 hp |
| Motor Voltage | 230V |
| No. Of Inch Threads | 34 |
| No. Of Longitudinal And Cross Feed Rates | 25 |
| No. Of Metric Threads | 34 |
| No. Of Motor Phase | 3 |
| Overall Dimensions | 68.5" x 28.3" x 50" |
| Range Of Cross Feeds | 25 |
| Range Of Inch Threads | 2-56 |
| Range Of Longitudinal Feeds | 0.0016-0.046 |
| Range Of Metric Threads | 0.5-12 |
| Range Of Spindle Speeds | 40-2000 RPM |
| Spindle Bore | 1 1/2" |
| Spindle Mount | D1-4 |
| Spindle Taper With Sleeve | MT-5 |
| Steady Rest Capacity | 0.23", 0.61", 0.2", 2.36" |
| Swing Over Bed | 14" |
| Swing Over Cross Slide | 9 1/16" |
| Tailstock Spindle Travel | 6 1/8" |
| Taper In Tailstock Spindle | MT-3 |
| Ship weight (kg) | 712.8 |
| Ship height (cm) | 127 |
| Ship length (cm) | 173.99 |
| Ship width (cm) | 71.88 |
| Country of Origin | TW |
